Add A New Preset Instructional Video





Press Setup on Remote:

The first screen is the Setup menu. Tuning / Preset is highlighted, Press OK.

To enter in a new service into a preset, push the YELLOW button, the next menu will have PRESET NUMBER highlighted. Next press OK and the first number will turn black. You can change this number either using the up down arrow or Direct enter the number using the remote numerical keys on the remote, press OK.  Then press the down arrow once, then OK.

NEXT

Scroll Down to Preset Name to name of the new programing service. Press the RED KEYBOARD BUTTON.
You can enter the letters using the remote Keyboard or push the up the down arrow keys to scroll through both lower and upper case letters. Once name is entered go to OK and press OK on remote.

NEXT

Scroll past LNB Configuration as it already set to 1 which is 5150Mhz (C band LNB ) stop on MODULATION TYPE. Using the left or right arrow set it to DVB-S2 or DVB-S as required by the service, Press OK.

NEXT

Scroll Down to DOWNLINK and enter in the the Frequency of the transponder. Make sure you enter any leading ZERO, so 4 GHz is 04.00000 Ghz. If your tuning  Ku band there is no leading ZERO example 12.110000 GHZ, Click OK to enter.

NEXT

Scroll down to SYMBOL RATE and click OK, Then enter the number (example 30000 MS/) then click OK again.

NEXT

Scroll down to NetId, Click OK and enter the NET ID. Rainier provides the proper NET ID number for our subscription services. NetId for a FTA services is usually 0.

NEXT

Once everything is entered correctly, position your dish on the satellite and polarity of the service you want to view.  Using either your 4DTV or Rainier Approved Dish Mover.  Press the BLUE button to ACTIVATE this scans that transponder in. You will get a warning, Changes may affect system settings screen, do not worry just Press OK. If you’re on the right satellite and polarity you will see Acquisition Successful or Acquisition Failed. If it failed check the satellite dish position and polarity setting on your 4DTV master receiver or mover.  With DVB-S2 polarity and position has to be exact, and this can be touchy sometimes. Tune slowly, if your dish is tracking the arc properly and you using the proper equipment you should have no problem getting reception. If you still have problems contact your local dish installer, Satellite Dealer or Rainier customer support for more information.
