LINKBOX 500i HD H.265 FTA/IPTV Satellite Receiver

« Store Home

Linkbox 500i HD H.265
FTA / IPTV Satellite Receiver


Low Cost TV Solution

$149.99

Plus Shipping.





The Linkbox 500i is a basic low cost solution to receive FTA Satellite and IP services. If your just starting out, looking for free TV or looking for a simple second receiver the Linkbox 500i is for you. No subscription required. Does not receive Rainier Satellite Subscription TV. Use our D9865 here for our pay programming. Availability of FTA channels may vary. Manufacture Warranty Applies.


Key Features

  • Fully HD up to 1080i/p
  • HEVC/H.265 Video decoding
  • WIFI support
  • Ethernet interface
  • BISS CAS Embeded
  • USB PVR ready : PVR / Time shift
  • Network Application supported : Youtube, Dailymotion, DLNA, Live TV, Weather forecast etc.
  • Automatic Firmware Update
  • NTP (Network Time Protocol)
Main Features

  • Fully Compliant of DVB-S & DVB-S2 (QPSK/8PSK/16APSK/32APSK) Digital & DVB broadcasting
  • Supports MPEG-2 MP@HL
  • Supports HEVC/H.265 MP@level 4.0 High tier
  • Supports H.264 BP (with no ASO/FMO), MP& HP@ L3/L4.1
  • Supports High Definition Video output : Digital Output
  • Full HD Resolution supported : 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
  • Audio Decoding : MPEG-1 Layer1,2&3(MP3), MPEG-2 layer2, MPEG-2 AAC
  • Satellite Tuner : 950-2150 MHz Input Frequency, Symbol rate 1-45 Msps
  • Very Fast Smart Search (Blind Scan)
  • Demodulation : QPSK/8PSK/16APSK/32APSK
  • USB PVR Ready : FAT16 / FAT32 / NTFS Format function, Recording, Playback, EPG Time record, Time shift
  • Multimedia File Playback by USB : Movie, Music, Photo
  • Fast Channel Change (< 1second)
  • Supports Teletext subtile / DVB subtitle
  • 10,000 channels TV & Radio channels
  • Channel Edittting Function : Favorite, Delete, Skip, Lock
  • 8 Favorite List
  • User-friendly EPG(Electronic Program Guide)
  • 16bits color OSD(On Screen Display)
  • Screen Format : 4:3, 16:9
  • Hardware Copy Protection
  • Software Upgrade through USB and Network.
  • Multiple LNB switching control : DiSeqC 1.2 and USALS Compatible
  • Network : 10/100M Full/Half Duplex Ethernet Interface supported
  • Automatic Firmware Update through Network.
  • Supports WIFI Remote Controller
  • DLNA supported
  • Network TV supported : LiveTV, M3U8 Player, User IPTV
  • Network Audio supported : Buddha audio, Quranic audio
  • Weather Forecasting
Tuner & Decoder

  • Tuner: DVB-S/S2 support
  • Frequency range: 950 ~ 2150 MHz
  • Input Level: -25 ~ 80dBm
  • Input Impedance: 75O
  • LNB Power: 13V/18V/OFF
  • DISEqC: 1.0 /1.2/USALS
  • LNB: 13/18V, 22 KHz Tone, DiSeqC 1.2 support
  • Demodulation: QPSK, 8PSK, 16APSK, 32APSK
  • Symbol rate: 1 ~ 45 MS/s
MPEG Transport Stream A/V Decoding

  • Transport stream: MPEG-2 ISO/IEC 13818-1
  • Input Bit Stream Rate: Max. 80Mbit/s @ MPEG2, Max. 60Mbit/s @ H.264/AVC
  • Video decoding:
      HEVC/H.265 MP@level 4.0 High tier
      MPEG-2 MP@HL
      H.264 BP (with no ASO/FMO), MP& HP@ L3/L4.1
      AVS Jizhun profile @ L6.0/ L4.0
      AVS Broadcast profile @ L6.0/ L4.0
      MPEG-4 SP Profile
      VC1 SP@ML, MP@HL, AP@L0~3
      H.263 baseline profile
  • Video output: Digital output
  • Video resolution: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
  • Aspect ratio: 4:3, 16:9
  • Audio decoding:
      PEG-1 Layer1,2&3(MP3), MPEG-2 layer2
      PEG-2 AAC
  • Audio mode: Stereo L/R
Main system

  • Main CPU: 32bit RISC CPU
  • Memory: DDR3 1Gb(128Mbyte)
  • Flash Memory: 8Mbyte SPI Flash
Front & Rear panel

  • LED: Power, Tuner Lock
  • USB: 1 X USB 2.0 Host Support
  • Ethernet: RJ-45
A/V & Data interface

  • HDMI: Support HDMI 1.4a (DVI mode support)
Power Supply

  • Type: SMPS
  • Input range: AC 110-240V, 50/60 Hz
  • Power Consumption: Max 20W
  • Standby mode: < 1W

Item ID: LBX500

In Stock
